Characteristics:
Opening type, convenient and prompt to enter and slide off the working position, with an integral tong head of great strength and rigidity.
Double swing head jaws, convenient to assemble and disassemble.
Brake belt assembly, easy to operate and convenient to maintain and replace.
Open gear supporting structure, improving the strength and rigidity.
Wholly hydraulic mode and mechanical gear shift, simple and reliable structure.
High strength steel plate used on the shell increasing the strength. The jaws are cast with precise technology, artistic and strong.
With hydraulic torque indicator and also installation interface, convenient to realize the computer management.
Use safety door hydraulic safety device good safety performance.
Large torque range can meet the requirement of larger torque use.
| 1 | Application range | 9 5/8″-24 1/2″ (245-622mm) | |
| 2 | Torque range | High：8800 ft·lbs/ 12000 N·m | Low：50000 ft·lbs/ 70000 N·m |
| @2300PSI / 16 MPa | |||
| 3 | Max RPM | High：30 RPM | Low：5.5 RPM |
| @50GPM / 187.5 LPM | |||
| 4 | Oil flow | 2320 PSI @50 GPM / 16 MPa @187.5 LPM | |
| 5 | Overall dimension (L×W×H) | 83.5″×53.2″×31.5″ / 2120×1350×800mm | |
| 6 | Weight | 3970 lbs / 1800 kg | |
